Accesorios para cajas
A9052209
SOFT-CASE L
Unique case construction with "orientation towards the width" in pocket-format. Recessed area for membrane keyboards. Fixing possibilities for PCBs in top and bottom part. Optional intermediate rings provide more installation height. With soft TPE ring (accessory) protection class IP 54 possible. Note: IR function only without intermediate ring/with intermediate ring in PMMA possible.
VersionWithout battery compartment
SupplyTop and bottom part, assembly kit
Cree su ficha de datos en PDF para A9052209
Seleccione la información del producto para su ficha de datos.
Accessory "intermediate ring"
A9152011
Supply 1 intermediate ring
A9152011
Intermediate ring Lmatt chromed
76x120x21mm
A9152017
Supply 1 intermediate ring
A9152017
Intermediate ring Loff-white RAL 9002
76x120x21mm
A9152018
Supply 1 intermediate ring
A9152018
Intermediate ring Llava
76x120x21mm
A9152118
Supply 1 intermediate ring
A9152118
Intermediate protection ring Lvolcano
76x120x21mm
A9152219
Supply 1 intermediate ring
A9152219
Intermediate ring Lblack RAL 9005
76x120x21mm
Accessory "wall/holder"
A9152049
Supply 1 set
A9152049
Combi-Clipblack RAL 9005
45x27mm
Accessory "carrying"
A9100001
Supply 1 ring eyelet
A9100001
Ring eyeletvolcano
A9152049
Supply 1 set
A9152049
Combi-Clipblack RAL 9005
45x27mm
Accessory "screws"
A0304031
Supply 1 self-tapping screw
A0304031
Self-tapping screws 2.2 x 5 mm (PZ1)Accessory
A9152059
Supply 1 tilt foot bar, assembly kit
A9152059
Tilt foot barblack RAL 9005
Necessary accessories: soft TPE intermediate ring,
Drawings (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN ISO 20457)
- PDF-File (without registration) 750 KB
- AutoCAD DWG-File 1.659 KB
- AutoCAD DXF-File 6.349 KB
- 3D PDF (Acrobat Reader) (girar el producto 360°, mostrar u ocultar componentes y accesorios, etc.) 1.442 KB
3D-Models (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN ISO 20457)
- 00008012.x_t 6.780 KB
- 00008012.STEP 16.262 KB
- 00008012.SAT 14.357 KB
(OKW product)
Servicio de personalización: Podemos modificar nuestras cajas para satisfacer sus requisitos específicos. Le entregaremos sus cajas totalmente acabadas y listas para usar. Lo único que tiene que hacer es instalar su equipo en su interior. Vea las opciones de personalización para A9052209 y no olvide solicitar presupuesto.
