B5015207

Bottom and top part O160 F

Assembly unit: Screw pillars for PCBs in top part. Screw pillars for battery compartment (acc.) in bottom part. Top part with recessed area for membrane keyboards. End piece (lid / battery compartment lid / base / base 30° or base 55°) required for bottom part - see separate article.

Version

Bottom part "inclined"

Supply

1 top and bottom part O160 F, assembly kit

  • Componentes adecuados
  • Modificaciones específicas del cliente

System components to complete

AltText

B5011117

Base Assembly unit: suitable for all bottom parts. Spacer for ceiling / wall mounting. Easy to mount with bayonet lock. If required it can be additionally secured using the anti-rotation device (acc.). Locators for 2 x AA and strain relief (acc.) in the base.

Supply 1 base

Cerrar

B5011117

Base
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002
AltText

B5011217

Base 30° Assembly unit: suitable for all "inclined" bottom parts for ergonomically installation and assembly angles. Easy to mount with bayonet lock. If required it can be additionally secured using the anti-rotation device (acc.).

Supply 1 base 30°

Cerrar

B5011217

Base 30°
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002
AltText

B5011317

Base 55° Assembly unit: suitable for all "inclined" bottom parts for ergonomically installation and assembly angles. Easy to mount with bayonet lock. If required it can be additionally secured using the anti-rotation device (acc.).

Supply 1 base 55°

Cerrar

B5011317

Base 55°
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002
AltText

B5011847

Lid Assembly unit: suitable for all bottom parts, screw-down (not suitable for use with battery compartment).

Supply 1 lid, assembly kit

Cerrar

B5011847

Lid
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002
AltText

B5011857

Battery compartment lid Assembly unit: suitable for all bottom parts when using battery compartment 2 x AAA (acc.), screw-down.

Supply 1 battery compartment lid, assembly kit

Cerrar

B5011857

Battery compartment lid
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002

Accessory "battery"

AltText

A9166001

Set of battery clips, 2 x AAA For contacting the batteries.

Supply 4 single contacts

Cerrar

A9166001

Set of battery clips, 2 x AAA
Producto añadido a su lista
Steel
tin-plated
AltText

A9166002

Battery contact, 2 x AAA In combination with battery contacts A9166001 it's possible to have a bridge connection and therefore a serial connection.

Supply 1 battery contact

Cerrar

A9166002

Battery contact, 2 x AAA
Producto añadido a su lista
Steel
tin-plated
AltText

A9166003

Battery holder, 2 x AAA The battery holder allows practically movement-free securing of the 2 x 1.5 V micro cells (AAA), thus ensuring that the internal power supply is securely located in position.

Supply 1 battery holder, 1 self-tapping screw

Cerrar

A9166003

Battery holder, 2 x AAA
Producto añadido a su lista
PA 6 (UL 94 HB)
black RAL 9005
AltText

A9190002

Set of battery clips, 2xN/2xAA/2xAAA For contacting the batteries.
Note application ART-CASE: only for base suitable (2 x AA).

Supply 1 double contact, 2 single contacts

Cerrar

A9190002

Set of battery clips, 2xN/2xAA/2xAAA
Producto añadido a su lista
Steel
tin-plated
AltText

B5111107

Battery compartment, 2 x AAA Application: For 2 x 1.5 V micro cells (AAA).

Supply 1 battery compartment, assembly kit

Cerrar

B5111107

Battery compartment, 2 x AAA
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002

Accessory "protection"

AltText

A9199005

Strain relief Frame for securing the cable on existing supports. Suitable for cable ø approx. 5-7 mm.

Supply 1 strain relief device, 2 screws

Cerrar

A9199005

Strain relief
Producto añadido a su lista
PA 6
volcano
AltText

B5111707

Anti-rotation device To prevent the base from being removed.

Supply Anti-rotation device, incl. screws

Cerrar

B5111707

Anti-rotation device
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002

Accessory "wall/holder"

AltText

B5111307

Wall mounting set Suitable for all versions (except Euro Plug version), for secure wall mounting of the enclosures (machining lid/bases necessary).

Supply Wall mounting set, incl. safety screw

Cerrar

B5111307

Wall mounting set
Producto añadido a su lista
ABS (UL 94 HB)
off-white RAL 9002

Accessory "screws"

AltText

B5111201

Set of screws Screw kit for mounting PCBs. Diameter 2.5 x 5 mm, type PZ1.

Supply 4 screws

Cerrar

B5111201

Set of screws
Producto añadido a su lista

Accessory

AltText

A9207150

Anti-slide feet 6.5 x 2 mm Rubber feet with self-adhesive foil facilitate a secure position.

Supply 2 rubber feet

Cerrar

A9207150

Anti-slide feet 6.5 x 2 mm
Producto añadido a su lista
transparent

Customising options for B5015207

What else do you need to create your own personal product? We can supply our enclosures and tuning knobs fully modified to suit your electronic components and design requirements. Please advise for anything else we can do for you.

  • Datos técnicos
  • Planos / Documentos
  • Ejemplos de aplicación
  • Purchasing Data
Color
off-white RAL 9002
Length
160 mm
Width
110 mm
Height
38 mm
PCB length, top
107 mm
PCB width, top
64 mm
Please take the dimensions from current parts. These are subject to material- and manufacturing-specific tolerances.

Drawings (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

3D-Models (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

Weight/1 part
81 g
Customs tariff number
(OKW product)
39269097
Country of manufacture
Germany
