C6009121
SMART-BOX WIDTH 90
Four-part plastic enclosure, ideal for design orientated electrical and electronic applications. The sealing is already prefitted in the top. Screw fixing outside of the sealing area. Resessed operating area to protect the membrane keyboard. Fastening pillars for PCBs and DIN-rails.
Supply1 base and top part with sealing, 2 trims, 1 assembly kit incl. cover retention
Generate Your PDF Datasheet for C6009121
Please select the product details you would like to include in the PDF.
Accessory "protection"
C2306917
Airflow: 6.5 L/min - 0.25 bar; 16.5 L/min - 1 bar.
Water entry pressure: > 6 bar.
Temperature range: -40°C/+110°C.
Sealing material: BASF Luquafleece + PA6 mesh (insert molding).
Supply 1 pressure equalisation element, 1 seal washer, 1 nut
C2306917
Pressure equalisation element M6x0.75light grey RAL 7035
C2310917
Airflow: 19.5 L/min - 0.25 bar; 43.5 L/min - 1 bar.
Water entry pressure: > 6 bar.
Temperature range: -40°C/+110°C.
Sealing material: BASF Luquafleece + PA6 mesh (insert molding).
Supply 1 pressure equalisation element, 1 seal washer, 1 nut
C2310917
Pressure equalisation element M10x1light grey RAL 7035
C2316147
Supply 1 cable grommet
C2316147
Cable grommetlight grey RAL 7035
C6100006
Supply 1 plug
C6100006
Security plugred
C6100016
Supply 2 plugs
C6100016
Set of securityred
Accessory "screws"
A0306031
Supply 1 self-tapping screw
A0306031
Self-tapping screws 3 x 6 mm (PZ1)
A0308031
Supply 1 self-tapping screw
A0308031
Self-tapping screws 3 x 8 mm (PZ1)
A0308132
Supply 1 self-tapping screw
A0308132
Self-tapping screw 3 x 8 mm (T10)Accessory
C2299018
Supply 4 case feet
C2299018
Case feetDrawings (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN ISO 20457)
- PDF-File (without registration) 373 KB
- AutoCAD DWG-File 1 107 KB
- AutoCAD DXF-File 4 217 KB
- Widok 3D PDF (Acrobat Reader) (obróć produkt o 360 °, elementy niewidoczne na zewnątrz, akcesoria...) 1 637 KB
3D-Models (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN ISO 20457)
- 00008153.x_t 8 613 KB
- 00008153.STEP 15 816 KB
- 00008153.SAT 19 122 KB
(OKW product)
