A9461107
EVOTEC 200, Vers. I
2-part plastic enclosure with flat top part. Robust design with tongue and groove connection. Case assembled with Torx drive stainless steel screws. Seal for protection class IP 65 available as an accessory. Fastening pillars for PCBs and components in the top and bottom parts. Wall suspension element ordered separately.
Version Top part "Flat"
Supply Top and bottom parts, assembly kit incl. 6 self-adhesive rubber feet
A9461107
EVOTEC 200, Vers. I产品已添加到关注清单中
off-white RAL 9002
200x124x45mm
,
A9465107
EVOTEC 200, Vers. II
2-part plastic enclosure with operating panel ergonomically inclined by 12°. Robust design with tongue and groove connection. Case assembled with Torx drive stainless steel screws. Seal for protection class IP 65 available as an accessory. Fastening pillars for PCBs and components in the top and bottom parts. Wall suspension element ordered separately.
Version Top part "Desktop" without recess
Supply Top and bottom parts, assembly kit incl. 6 self-adhesive rubber feet
A9465107
EVOTEC 200, Vers. II产品已添加到关注清单中
off-white RAL 9002
200x124x45mm
,
A9466107
EVOTEC 200, Vers. III
2-part plastic enclosure with operating panel ergonomically inclined by 12°. Top part with recessed area for protecting a membrane keypad or decor foil. Robust design. Case assembled with Torx drive stainless steel screws. Seal for protection class IP 65 available as an accessory. Fastening pillars for PCBs and components in the top and bottom parts. Wall suspension element ordered separately.
Version Top part "Desktop", operating area recessed by 1 mm
Supply Top and bottom parts, assembly kit incl. 6 self-adhesive rubber feet
A9466107
EVOTEC 200, Vers. III产品已添加到关注清单中
off-white RAL 9002
200x124x45mm
,
Please take the dimensions from current parts. These are subject to material- and manufacturing-specific tolerances.
Weight/1 part
1 g
Customs tariff number
(OKW product)
(OKW product)
40081900
Country of manufacture
Germany
