DIN modulární skříňka
B7040229
ERGO-CASE XS
Three-part enclosure in ergonomic design to wear on the body. Wrist strap as accessories. TPE ring for a pleasant touch sensation. Fastening pillars and fixing supports for PCBs and integrated parts in the bottom and top part. Recessed operating area for the protection of the membrane keyboard.
VersionTPE ring with two eyelet holes
Supplytop and bottom part, ring, assembly kit
Generovat PDF pro B7040229
Vyberte prosím podrobnosti o produktu, které chcete zahrnout do PDF.
Accessory "carrying"
B7110129
Supply 1 belt strap
B7110129
Belt strap450x35mm
B9100033
Supply 1 wrist strap
B9100033
Wrist strap280mm
Bottom and top part
Intermediate ring
Intermediate ring volcano
Drawings (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN ISO 20457)
- PDF-File (without registration) 210 KB
- AutoCAD DWG-File 444 KB
- AutoCAD DXF-File 1 502 KB
- 3D PDF (Acrobat Reader) (otočte produkt o 360°, zrušte zobrazení komponentů pro náhled z vnitřní strany…) 2 631 KB
3D-Models (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN ISO 20457)
- 00013247.x_t 4 850 KB
- 00013247.STEP 9 363 KB
- 00013247.SAT 13 350 KB
(OKW product)
Možnosti úprav: Zapouzdření můžeme upravit tak, aby vyhovovala Vašim specifickým požadavkům. Zapouzdření dodáme kompletně dokončená a připravená k použití. Už bude zbývat pouze instalace Vašich součástek nebo elektroniky. Prohlédněte si možnosti úprav pro B7040229 a nezapomeňte si vyžádat nabídku!
